ABB 1TGE120021R0010 模拟量输出模块

产品详细说明

ABB’s 1TGE120021R0010 is an analog output module mainly used to convert analog signals from control systems into voltage or current signals that can be used to drive actuators. This type of module is an important component of control systems and is widely used in various application scenarios, such as industrial control, building automation, HVAC control, and power generation.

This module has two analog output channels, each with a 12 bit resolution, and the output range can be 0 to 10 V or 4 to 20 mA. In addition, it also has optional isolation function and supports DIN rail installation. In terms of configuration and usage, this module provides great flexibility, allowing for remote transmission of concentration alarm levels, maintenance requirements, service status, and instrument fault messages.

In addition, the module also supports a comprehensive Modbus protocol, making remote communication and device inquiries possible through RS485. At the same time, users can also choose Ethernet connections to achieve more flexible and efficient data transmission.

Overall, ABB’s 1TGE120021R0010 analog output module is a powerful and flexible product suitable for various complex control systems. However, for specific application scenarios and configuration requirements, users may need to make choices and adjustments based on actual situations.

技术特点

1. 硬件设计
   • 基于芯片技术的 PLC 设计，可在苛刻环境下使用。
   • 外壳密封防水，标准外壳可潜水至三英尺，适合恶劣工业环境。
   • 模块化设计，便于维护和升级。
2. 输入输出配置
   • 6 个 8-32VDC 输入，其中 2 个为独立现场选择下沉或采购输入。
   • 提供 40kHz 高速计数功能，满足高精度计数需求。
   • 2 个 10 位模拟通道，可选择 0-5VDC、0-10VDC 或 0-20mA 范围。
   • 6 个数字/压水管输出，额定电流为 4 安培，每个输出具备自动过电流安全和可编程状态监测功能。
3. 编程与配置
   • 使用迪维斯梯子软件编程，支持阶梯图和功能块编程，简化开发流程。
   • 支持灵活配置选项，可根据具体应用需求定制功能。

4. 应用场景

5. 电力系统保护与控制
   • 用于次级输电网络应用，如单母线或双母线接线方式下的单断路器间隔控制。
   • 提供母联间隔控制功能，增强系统灵活性。
   • 适用于单母线单断路器、双母线单断路器、带有母联的双母线等多种接线方式。
6. 工业自动化
   • 作为 PLC 使用，支持高速计数、模拟量输入输出等功能，适用于生产线监控、设备控制等场景。
   • 通过丰富的通信接口，实现与 HMI、SCADA 系统等设备的无缝集成。
7. 能源管理
   • 实时监测电网参数，为能源调度和优化提供数据支持。
   • 支持电能计量功能，可用于电能统计和结算
