5SHY5045L0020 ABB 可控硅晶闸管不仅具有单向导电性

The 5SHY5045L0020 thyristor is a type of module for power control and conversion, belonging to the IGCT (Integrated Gate commutated thyristor) series. This kind of thyristor combines the advantages of stable switching ability of transistor and low on-state loss of thyristor, so that it can exert the performance of thyristor in the on-stage, and show the characteristics of transistor in the off stage.

Specifically, the thyristor integrates the GTO chip with an anti-parallel diode and a gate drive circuit, which is then connected to its gate driver in a low-inductance manner at the periphery. This design makes the thyristor have the characteristics of high efficiency, wide input range, high efficiency heat dissipation design and easy to use.

In practical applications,  thyristors can be used in a variety of industrial application scenarios that require high efficiency, reliability and programmability. Due to its efficient power control and conversion capabilities, it is often used in large power electronics packages developed by medium-voltage inverters to provide stable and reliable power support for industrial automation and control systems.

Overall, the thyristor is a full-featured, stable power control and conversion module suitable for a variety of industrial application scenarios. However, when using this thyristor, it is necessary to follow the relevant installation and use specifications to ensure its normal operation and extend its service life. At the same time, for specific application scenarios, it may be necessary to customize the design and configuration to meet the specific power control and conversion requirements.

IGCT (Integrated gate-commutated Thyristor) is an integrated gated thyristor, while IGBT (Insulated Gate Bipolar Transistor) is an insulated Gate bipolar transistor. They are both switching devices for high power electronic devices, but the two differ in structure and working principle.

ABB 5SHY3545L0009 3BHB013085R0001 IGCT系列模块 IGCT集成门极换流晶闸管(Intergrated Gate Commutated Thyristors)是一种中压变频器开发的用于巨型电力电子成套装置中的电力半导体开关器件(集成门极换流晶闸管=门极换流晶闸管+门极单元)。 1997年由ABB公司提出。IGCT使变流装置在功率、可靠性、开关速度、效率、成本、重量和体积等方面都取得了巨大进展，给电力电子成套装置带来了新的飞跃。 IGCT是将GTO芯片与反并联二极管和门极驱动电路集成在一起，再与其门极驱动器在外围以低电感方式连接，结合了晶体管的稳定关断能力和晶闸管低通态损耗的优点， 在导通阶段发挥晶闸管的性能，关断阶段呈现晶体管的特性。IGCT 具有电流大、阻断电压高、开关频率高、可靠性高、结构紧凑、低导通损耗等特点，而且造成本低，成品率高，有很好的应用前景。
